Locking pin

　　1. Material: 45 # steel;

　　2. Shaft diameter φ 15.95- φ 16.00mm;

　　3. Surface roughness: Ra0.8;

　　4. Surface treatment: quenching and tempering or hardening treatment;

　　5. Surface hardness: hv280-400;

　　6. Shear force: 25KN/cm ²;

　　7. Locking force: 600kg;

　　8. Clamping force: 1 ton.
